Eight-Torch Plasma Ignition Gun
TYDZ-1 is a plasma ignition torch built as a front end: eight linked igniters are assembled into one gun, and when the unit is energised the plasma discharge forms at the front end of that assembly, where it meets the fuel and air at the burner throat.
A front end, not the whole system. The gun does not generate the pulse — it delivers it. Behind it sit the plasma ignition power unit and the cable that carries the high-frequency, high-voltage supply; in front of it are the fuel, the air and, where the plant verifies light-off, the flame detector. We build all four, which is why plants come to us as a plasma ignition system supplier rather than assembling a chain from separate vendors.
Where it belongs. This is the part chosen when the ignition zone is wider than one torch can cover, and the burner needs several points alight at once instead of a flame that has to travel from a single origin. Boiler and furnace maintenance teams fit it at a planned outage; combustion engineers specify it when a burner front wall is rebuilt or a unit is converted.
How the Eight-Torch Head Is Built
- Eight torches, one body. The eight igniters are linked into a single gun body instead of being hung separately around the burner mouth, so one mounting position carries all eight points and their position relative to each other is fixed when the head is assembled.
- Threaded joints between sections. Each section screws into the next, which lets the assembly be broken down for transport, opened for inspection, and repaired one section at a time rather than scrapped as a sealed unit.
- Pin contacts carry the supply. Inside the body the electrical path is made through pin contacts. There is no external jumper loom running between the torches, so nothing hangs loose on a hot front wall to snag, chafe or work free.
- Stainless steel outer structure. The outer body is stainless steel, chosen for a part that lives at the burner mouth: it holds its shape under radiant heat, resists oxidation, and does not scale away where the temperature is highest.
- Ceramic internal insulation. Between the live path and the steel shell sits ceramic insulation, so the pulse is delivered to the torches rather than to the body, the mounting or the burner plate.
- One assembly to handle at the outage. Because the sections thread together and the electrical path runs inside, the head is removed, inspected and refitted as one item, and the alignment of the eight points survives the operation.
Multi-Point Ignition in Service
Coal-fired boiler light-off. On a coal-fired unit the plasma igniter torch for coal fired boilers is asked to do more than drop a spark into one corner of the throat. Coal needs an ignition source with enough spread and enough contact with the fuel stream to start the whole flow, and eight points across the mouth give the flame several places to establish at once. Once the fuel is lit, the gun is shut down and the burner carries the flame on its own.
Wide throats and multi-burner front walls. A single plasma ignition torch lights one spot, and the flame then has to travel across the throat before the burner stabilises. A multi-point head shortens that travel and evens out the temperature across the front, which matters most on wide throats and on walls where several burners are started in sequence.
Retrofits from a row of single torches. Plants that have been running a row of individual ignition guns often consolidate onto one head: one penetration in the wall instead of several, one cable to route, one assembly to pull at the outage, and one set of joints to check instead of a row of separate fittings.
What the head does not decide. The firing sequence is not set by the gun. Whether all eight points fire together or in banks as the burner comes up is governed by the power unit and control scheme behind it, so agree that sequence before the internal pin arrangement is finalised.
Mounting and Connection
- Measure the burner port first. Burner ports differ from plant to plant, and on a plasma igniter torch for coal fired boilers the thread, bore and wall thickness decide how deep the head sits — so take all three before anything else is done.
- Check the mating connector on your cable against the pin contacts in the gun. Pin count and arrangement have to match before the first energisation, not after the burner is closed up.
- Thread the sections together on the bench and check that the assembly runs straight. A joint started cross-threaded in a hot port turns a short job into a long outage.
- Offer the head into the port and align the front face square to the throat. Never use the burner wall to pull the assembly into line; it loads the threaded joints in a direction they were not made for.
- Carry out the first energisation with the burner purged, following the commissioning procedure your plant works to, and confirm that plasma forms at the front end of every point.
- Record the thread size, the fitted depth and the section order in the maintenance file, so the next replacement is ordered from a record rather than a fresh measurement.
- Where the burner has flame detection, confirm the detector picks up the flame the gun has just established before the light-off sequence is signed off.
Matching Parts and Spares
- The power unit behind the gun. This item is the front end only, so the plasma ignition power unit has to suit it. Match the two on output and on the firing sequence you want, not on the gun alone.
- The ignition cable. The pulse travels from the power unit to the gun through a high-frequency, high-voltage cable, and the run length is set by the distance between the two. Order the cable with the run measured, not with a nominal length.
- Flame detection on the same front wall. Where the plant verifies light-off, a UV detector or probe mounted alongside confirms the flame the gun has established, and the detection chain can be ordered with the gun.
- Spare torch sections. Because the body is threaded, an eroded or damaged section can be unscrewed and replaced without scrapping the head. Ask which sections are supplied separately before you set a spares level for the plant.
- One interface drawing. As a plasma ignition system supplier we build gun, cable and detector from the same drawing set, so thread, pin arrangement and cable entry are agreed together instead of being reconciled across three suppliers on site.
Ordering and Delivery
- Send the burner port details — thread, bore, wall thickness and the space behind the wall — with a photo of the existing plasma ignition torch and a tape measure held across the thread. Dimensions matter more than model names, because two boilers of the same make rarely share a port.
- Describe the firing sequence you want: all eight points together, or staged as the burner comes up. The pin arrangement inside the body and the cable are agreed against that sequence.
- State the quantity — one gun for a single burner or a set for a front wall — and say whether spare sections go into the same order for your outage plan.
- Confirm the commercial terms with your sales contact. Minimum order quantity, unit price, payment terms, lead time and shipping method are quoted for each order and are not published as standing figures.
- Agree the packing. The gun travels in a hard-shell case with foam cut-outs that hold the sections and their fittings apart; if it is going by sea freight, say so when the order is placed so the export packing matches the route.
- Ask for the documentation your plant files with an installation — outline drawings, the inspection record, or the material details — at the time of ordering, so they are prepared alongside the goods.
- Send everything in one message, and as a plasma ignition system supplier we answer with the confirmed assembly, the interface details and the delivery schedule for your order.
Technical Support & Model Matching
Not every buyer arrives knowing which item in the range fits. Tell us what the part has to do, the space it goes into and the supply you have, and our engineers check it against the specifications we publish and tell you which model matches — and when a standard item will not do. The same team designs, builds and tests the products in our own plant in Shaanxi: 28 people, 16 patents, national high-tech enterprise status, in business since 2018. They answer questions before you order, stay reachable afterwards for fitting questions and fault-finding, and take custom or non-standard requests directly.
FAQ
Do all eight igniters fire at once, or can they be staged?
That is settled at the interface rather than by the gun alone. The eight torches are fed through the pin contacts inside the body, so whether they fire together or in banks as the burner comes up is agreed when the pin arrangement is set. Tell us the sequence your control scheme uses before the order is placed and the internal arrangement is matched to it.
How do we confirm the thread and depth will fit our burner port?
Measure the port — thread, bore and wall thickness — and send the figures with a photo of the gun being replaced, with a tape held across the thread. Burner ports are not standard across boilers, and the head has to sit at a depth where the discharge lands in the fuel stream rather than at the port face. We check the assembly against those measurements before it is built.
What happens when one torch section erodes?
The head comes apart at the threaded joints, so a worn section can be unscrewed and replaced instead of the whole assembly being scrapped. Note the section order and the fitted depth when the gun is first installed, and the same positions can be restored at the next outage.
How is the high voltage kept away from the steel body?
Ceramic insulation separates the live path from the stainless shell, and the supply reaches each torch through pin contacts inside the body rather than through exposed jumpers. That is what allows the outside of the gun to stay a structural part — threaded and mounted like the pipework around it.
Will this plasma igniter torch for coal fired boilers also suit a gas or oil burner?
The head is not tied to one fuel. What decides the fit is the port geometry, the power unit behind it and the light-off sequence the burner runs. Multi-point ignition is most often specified for coal and for wide throats where a single origin is not enough, and the same assembly is used on other furnace fronts. Send the burner details and we will say whether this arrangement suits it.
How do we deal with slag or ash on the front end?
The front end sits in the throat and collects the same ash and slag as the rest of the burner mouth. Clean it with the burner cold and the head removed, and check that the torch tips are clear before the next light-off — a bridge of slag across the front changes where the discharge forms and makes light-off uneven.
